XB5AW35M5 | Schneider Electric

Pushbutton, illuminable, groping, 1 Form A (N/O) + 1 Form B (N/C), waistband round, orange, front ring black, mounting Ø 22 mm, XB5AW35M5

Order No.: 05P3361
EAN: 4099889227499
MPN:
XB5AW35M5
Series: Harmony XB5
XB5AW35M5 Schneider Electric Actuators, Signal Elements and Front Elements
Image may differ
Unit Price (€ / pc.)
32.9749 € *
Standard delivery time from the manufacturer is: 1 Week
Total Price:
32.97 € *
*incl. VAT plus shipping costs
Subject to prior sale
1 pcs.
32.9749 €

Illuminated pushbutton, XB5AW35M5, Schneider Electric

This Harmony XB5, illuminated modular orange push button operates with a spring return mechanism, is supplied with 220V to 240V AC, uses an integral LED and screw clamp terminals. This illuminated push button provides an ergonomic and visual interface for controlling your machines. It is easily installed into standard 22mm diameter panel cut-outs and connected to control circuits with classic screw-clamp connections. It is clearly distinguishable visually at a distance thanks to a bright and long lasting LED illumination. It is impact resistant, dust resistant, water resistant and vibration resistant thanks to its IP66 / IP67 / IP69 / IP69K, making it ideal for operation in harsh environments. Its plastic bezel makes it ideal for applications requiring good resistance to chemical agents and/or double electrical insulation.

Technical specifications
Contact function groping
Installation diameter 22 mm
Front ring colour black
Actuator colour orange
Product type pushbutton
Connection screw connection
Protection class IP66
Latching switching function 1 Form A (N/O) + 1 Form B (N/C)
Contact material silver alloy
Collar shape of the front frame round
can be illuminated Yes
Logistics
Country of origin FR
Customs tariff number 85365080
Compliance
Date of RoHS guidelines 3/31/15
Substance description Lead
SVHC free No
RoHS conform Yes
Sustainable Yes
