DC filter, 50 to 60 Hz, 32 A, 130 V (DC), 130 VAC, Threaded bolt, FN7562-32-M4

default S
default L
Total price
(69.37 € * / pcs.)
0.00 €
Currently not in stock, we will order for you
Quantity
Price per unit*
10 pcs.
69.37 €
*incl. VAT plus shipping costs
Description

Product by Schaffner at Bürklin Elektronik

Capacitor, FN7562-32-M4, SCHAFFNER

The FN7562-32-M4 is a feedthrough capacitor that offers a high insertion loss across a broad band of frequencies from a few tens of kHz up to the GHz region. This product cause a better suppression performance over a much wider frequency range than a conventional two-wire capacitor of equivalent value.

Features

  • High quality and reliability
  • Anti-twist protection
  • Rated currents from 10 to 200 A
  • Class Y4 capacitor

Applications

  • Increasing system and information security
  • Switching and cellular equipment
  • UPS power supplies
  • Computer server
  • Medical equipment
Technical specifications
Connection Threaded bolt
Version DC filter
Rated Voltage 130 VAC
integrated switch No
Capacity X|Y Y4 100 nF
max. frequency 0.00006 MHz
max. operating temperature 100 °C
min. frequency 0.00005 MHz
min. operating temperature -40 °C
With fuse No
Rated voltage (DC) 130 V
Rated current 32 A
Show similar products (0)
Logistics
Country of origin CN
Customs tariff number 85363010
Original Packaging Carton with 10 pieces
Compliance
RoHS conform Yes
Date of RoHS guidelines 3/31/15
SVHC free Yes
Variations
1 item with 5 variations
Item description
Price list
Total
Version
Rated Voltage
Capacity X|Y
max. frequency
Connection
min. operating temperature
Rated voltage (DC)
max. operating temperature
Rated current
min. frequency
DC filter, 50 to 60 Hz, 32 A, 130 V (DC), 130 VAC, Threaded bolt, FN7562-32-M4
Order No.:
 71D1003
Manufacturer:
 Schaffner
Manufacturer SKU
 FN7562-32-M4
10 pcs.
69.37 €
0.00 € *
Currently not in stock, we will order for you
DC filter
130 VAC
Y4 100 nF
0.00006 MHz
Threaded bolt
-40 °C
130 V
100 °C
32 A
0.00005 MHz
DC filter, 50 to 60 Hz, 16 A, 130 V (DC), 130 VAC, Threaded bolt, FN7562-16-M4
Order No.:
 71D1002
Manufacturer:
 Schaffner
Manufacturer SKU
 FN7562-16-M4
10 pcs.
63.05 €
0.00 € *
Currently not in stock, we will order for you
DC filter
130 VAC
Y4 100 nF
0.00006 MHz
Threaded bolt
-40 °C
130 V
100 °C
16 A
0.00005 MHz
DC filter, 50 to 60 Hz, 63 A, 130 V (DC), 130 VAC, Threaded bolt, FN7562-63-M6
Order No.:
 71D1004
Manufacturer:
 Schaffner
Manufacturer SKU
 FN7562-63-M6
10 pcs.
81.97 €
0.00 € *
Currently not in stock, we will order for you
DC filter
130 VAC
Y4 100 nF
0.00006 MHz
Threaded bolt
-40 °C
130 V
100 °C
63 A
0.00005 MHz
DC filter, 50 to 60 Hz, 100 A, 130 V (DC), 130 VAC, Threaded bolt, FN7562-100-M8
Order No.:
 71D1005
Manufacturer:
 Schaffner
Manufacturer SKU
 FN7562-100-M8
10 pcs.
102.55 €
0.00 € *
Currently not in stock, we will order for you
DC filter
130 VAC
Y4 470 nF
0.00006 MHz
Threaded bolt
-40 °C
130 V
100 °C
100 A
0.00005 MHz
DC filter, 50 to 60 Hz, 200 A, 130 V (DC), 130 VAC, Threaded bolt, FN7562-200-M10
Order No.:
 71D1006
Manufacturer:
 Schaffner
Manufacturer SKU
 FN7562-200-M10
10 pcs.
114.29 €
0.00 € *
Currently not in stock, we will order for you
DC filter
130 VAC
Y4 1000 nF
0.00006 MHz
Threaded bolt
-40 °C
130 V
100 °C
200 A
0.00005 MHz
