RI425 | Schaffner
Saturating choke, radial, 250 µH, 25 A, RI425
Order No.: 71D1895
EAN: 7612774450344
MPN:
RI425
800086
Unit Price (€ / pc.)
41.3287 € *
Standard delivery time from the manufacturer is: On Request
Saturating choke, RI425, SCHAFFNER
The RI425 is a RI saturating type choke. It changes impedance at the moment of switching, and can be used to attenuate differential-mode noise or symmetrical interference as generated in fast switching high current applications.
Features
- Excellent thermal behavior
- Single or dual-choke configurations
- Through hole or wire connections
- Up to 25 A single configuration
Applications
- Suppressing high interference levels generated by fast switching circuits
- EMC/EMI filters
- Phase angle control circuits
- Power supplies
Technical specifications
| Filter | Property | Value |
|---|---|---|
| DC current | 25 A | |
| DC resistance | 4 mΩ | |
| Length | 48 mm | |
| Height | 43 mm | |
| Width | 48 mm | |
| Inductance | 250 µH | |
| Design | radial | |
| Version | saturating choke |
Download
Logistics
| Property | Value |
|---|---|
| Country of origin | TH |
| Original Packaging | Carton with 56 pieces |
| Customs tariff number | 85045000 |
Compliance
| Property | Value |
|---|---|
| Date of RoHS guidelines | 3/31/15 |
| RoHS conform | Yes |
| SVHC free | Yes |
