RI406PC | Schaffner
Saturating choke, radial, 1.2 mH, 6 A, RI406PC
Order No.: 71D1892
EAN: 7612774450313
MPN:
RI406PC
800083
Unit Price (€ / pc.)
13.5065 € *
Standard delivery time from the manufacturer is: On Request
Saturating choke, RI406PC, SCHAFFNER
The RI406PC is a RI saturating type choke. It changes impedance at the moment of switching, and can be used to attenuate differential-mode noise or symmetrical interference as generated in fast switching high current applications.
Features
- Excellent thermal behavior
- Single or dual-choke configurations
- Through hole or wire connections
- Up to 25 A single configuration
Applications
- Suppressing high interference levels generated by fast switching circuits
- EMC/EMI filters
- Phase angle control circuits
- Power supplies
Technical specifications
| DC current | 6 A | |
| Width | 28.5 mm | |
| Height | 21.5 mm | |
| Length | 28.5 mm | |
| DC resistance | 53 mΩ | |
| Version | saturating choke | |
| Design | radial | |
| Inductance | 1.2 mH |
Download
Logistics
| Country of origin | TH |
| Customs tariff number | 85045000 |
| Original Packaging | Carton with 300 pieces |
Compliance
| Date of RoHS guidelines | 3/31/15 |
| SVHC free | Yes |
| RoHS conform | Yes |
