Saturating choke, radial, 1.8 mH, 3 A, RI403PC

default S
default L
Total price
(9.15 € * / pcs.)
0.00 €
Currently not in stock, we will order for you
Quantity
Price per unit*
100 pcs.
9.15 €
*incl. VAT plus shipping costs
Description

Product by Schaffner at Bürklin Elektronik

Saturating choke, RI403PC, SCHAFFNER

The RI403PC is a RI saturating type choke. It changes impedance at the moment of switching, and can be used to attenuate differential-mode noise or symmetrical interference as generated in fast switching high current applications.

Features

  • Excellent thermal behavior
  • Single or dual-choke configurations
  • Through hole or wire connections
  • Up to 25 A single configuration

Applications

  • Suppressing high interference levels generated by fast switching circuits
  • EMC/EMI filters
  • Phase angle control circuits
  • Power supplies
Technical specifications
Version saturating choke
Design radial
Width 23.3 mm
DC current 3 A
DC resistance 0.105 Ω
Height 18 mm
Inductance 1.8 mH
Length 23.3 mm
Show similar products (0)
Logistics
Country of origin TH
Customs tariff number 85045000
Original Packaging Carton with 100 pieces
Compliance
Guidline date 3/31/15
RoHS confom Yes
SVHC date 1/17/22
SVHC free Yes
Variations
1 item with 7 variations
Item description
Price list
Total
Design
Version
Width
Length
Height
Inductance
DC current
DC resistance
Saturating choke, radial, 1.2 mH, 6 A, RI406PC
Order No.:
 71D1892
Manufacturer:
 Schaffner
Manufacturer SKU
 RI406PC
300 pcs.
13.84 €
0.00 € *
Currently not in stock, we will order for you
radial
saturating choke
28.5 mm
28.5 mm
21.5 mm
1.2 mH
6 A
0.053 Ω
Saturating choke, radial, 1 mH, 10 A, RI410PC
Order No.:
 71D1893
Manufacturer:
 Schaffner
Manufacturer SKU
 RI410PC
300 pcs.
16.26 €
0.00 € *
Currently not in stock, we will order for you
radial
saturating choke
33 mm
33 mm
28 mm
1 mH
10 A
0.028 Ω
Saturating choke, radial, 250 µH, 25 A, RI425
Order No.:
 71D1895
Manufacturer:
 Schaffner
Manufacturer SKU
 RI425
56 pcs.
39.23 €
0.00 € *
Currently not in stock, we will order for you
radial
saturating choke
48 mm
48 mm
43 mm
0.25 mH
25 A
0.004 Ω
Saturating choke, radial, 1.8 mH, 3 A, RI403PC
Order No.:
 71D1891
Manufacturer:
 Schaffner
Manufacturer SKU
 RI403PC
100 pcs.
9.15 €
0.00 € *
Currently not in stock, we will order for you
radial
saturating choke
23.3 mm
23.3 mm
18 mm
1.8 mH
3 A
0.105 Ω
Saturating choke, radial, 3 mH, 1.5 A, RI401PC
Order No.:
 71D1890
Manufacturer:
 Schaffner
Manufacturer SKU
 RI401PC
100 pcs.
9.50 €
0.00 € *
Currently not in stock, we will order for you
radial
saturating choke
19.5 mm
19.5 mm
15 mm
3 mH
1.5 A
0.62 Ω
Saturating choke, radial, 300 µH, 15 A, RI415
Order No.:
 71D1894
Manufacturer:
 Schaffner
Manufacturer SKU
 RI415
77 pcs.
25.93 €
0.00 € *
Currently not in stock, we will order for you
radial
saturating choke
49 mm
35 mm
34 mm
0.3 mH
15 A
0.008 Ω
Saturating choke, radial, 3 mH, 6 A, RI111PC
Order No.:
 71D1889
Manufacturer:
 Schaffner
Manufacturer SKU
 RI111PC
42 pcs.
27.93 €
0.00 € *
Currently not in stock, we will order for you
radial
saturating choke
35 mm
49 mm
34 mm
3 mH
6 A
0.042 Ω
