SA 70413 201 053 | Saft
Nickel-cadmium-battery, 1.2 V, 1.3 Ah, KR22C429, Cs, soldering lug, SA 70413 201 053
Order No.: 26A6705
EAN: 4099891652623
MPN:
SA 70413 201 053
Unit Price (€ / pc.)
22.7171 € *
Available: 0 pcs.
Leadtime: On Request **
NiCd accumulators with special contacts, type Saft VR../VRE.
Suitable for use as round cell in heatshrink tubing
With tap type C, type VRE.
With two different ring solder lugs (open for plus, closed for minus), each with one solder tab.
Technical specifications
| Nominal capacity | 1.3 Ah | |
| Size | Cs | |
| other designation | Sub-C | |
| Technology | nickel-cadmium | |
| Usage | general applications | |
| diameter | 22 mm | |
| IEC designation | KR22C429 | |
| Height | 41.9 mm | |
| min. operating temperature | 0 °C | |
| Connection | soldering lug | |
| max. operating temperature | 50 °C | |
| Rated voltage | 1.2 V |
Download
Logistics
| Country of origin | FR |
| Customs tariff number | 85073020 |
Compliance
| Date of RoHS guidelines | 3/31/15 |
| Substance description | Cadmium, Cadmium hydroxide |
| SVHC free | No |
| RoHS conform | not_relevant |
