400SGV33M16X21.5 | Rubycon
Electrolytic capacitor, 33 µF, 400 V (DC), ±20 %, SMD, Ø 16 mm, 400SGV33M16X21.5
Unit Price (€ / pc.)
2.4276 € *
Available: 18 pcs.
Total Price:
4.86 € *
Price list
Quantity
Price per unit*
2 pcs.
2.4276 €
10 pcs.
2.1182 €
50 pcs.
1.8802 €
250 pcs.
1.7017 €
500 pcs.
1.5946 €
*incl. VAT plus shipping costs
Subject to prior sale
Electrolytic capacitor, 400SGV33M16X21.5, RUBYCON
Aluminum electrolytic capacitor
Features
- Load Life: 105℃ 2000～5000 hours
- Lead free reflow soldering
- AEC-Q200
Technical specifications
| Filter | Property | Value |
|---|---|---|
| diameter | 16 mm | |
| ESR (Equivalent Series Resistance) | 320 mΩ | |
| Rated voltage (DC) | 400 V | |
| max. operating temperature | 105 °C | |
| Tolerance | ±20 % | |
| Length | 21 mm | |
| Capacity | 33 µF | |
| min. operating temperature | -25 °C | |
| Ripple current | 320 mA | |
| Design | SMD | |
| Version | polar |
Download
Logistics
| Property | Value |
|---|---|
| Country of origin | JP |
| Customs tariff number | 85322200 |
Compliance
| Property | Value |
|---|---|
| Date of RoHS guidelines | 3/31/15 |
| RoHS conform | Yes |
| SVHC free | Yes |
