400SGV2R7M8X10.5 | Rubycon
Electrolytic capacitor, 2.7 µF, 400 V (DC), ±20 %, SMD, Ø 8 mm, 400SGV2R7M8X10.5
Unit Price (€ / pc.)
0.5831 € *
Standard delivery time from the manufacturer is: On Request
Total Price:
5.83 € *
Price list
Quantity
Price per unit*
10 pcs.
0.5831 €
50 pcs.
0.4522 €
250 pcs.
0.3927 €
1000 pcs.
0.3451 €
2000 pcs.
0.3094 €
*incl. VAT plus shipping costs
Subject to prior sale
Electrolytic capacitor, 400SGV2R7M8X10.5, RUBYCON
Aluminum electrolytic capacitor
Features
- Load Life: 105℃ 2000～5000 hours
- Lead free reflow soldering
- AEC-Q200
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Ripple current | 55 mA | |
| min. operating temperature | -25 °C | |
| max. operating temperature | 105 °C | |
| Version | polar | |
| diameter | 8 mm | |
| Rated voltage (DC) | 400 V | |
| Tolerance | ±20 % | |
| Capacity | 2.7 µF | |
| ESR (Equivalent Series Resistance) | 45 mΩ | |
| Design | SMD | |
| Length | 10 mm |
Download
Logistics
| Property | Value |
|---|---|
| Customs tariff number | 85322200 |
| Country of origin | JP |
Compliance
| Property | Value |
|---|---|
| RoHS conform | Yes |
| SVHC free | Yes |
| Date of RoHS guidelines | 3/31/15 |
