400SGV22M16X16.5 | Rubycon
Electrolytic capacitor, 22 µF, 400 V (DC), ±20 %, SMD, Ø 16 mm, 400SGV22M16X16.5
Unit Price (€ / pc.)
1.9397 € *
Standard delivery time from the manufacturer is: On Request
Total Price:
5.82 € *
Price list
Quantity
Price per unit*
3 pcs.
1.9397 €
15 pcs.
1.6898 €
75 pcs.
1.4994 €
400 pcs.
1.3566 €
800 pcs.
1.2733 €
*incl. VAT plus shipping costs
Subject to prior sale
Electrolytic capacitor, 400SGV22M16X16.5, RUBYCON
Aluminum electrolytic capacitor
Features
- Load Life: 105℃ 2000～5000 hours
- Lead free reflow soldering
- AEC-Q200
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Ripple current | 280 mA | |
| min. operating temperature | -25 °C | |
| max. operating temperature | 105 °C | |
| Version | polar | |
| diameter | 16 mm | |
| Rated voltage (DC) | 400 V | |
| Tolerance | ±20 % | |
| Capacity | 22 µF | |
| ESR (Equivalent Series Resistance) | 280 mΩ | |
| Design | SMD | |
| Length | 16 mm |
Download
Logistics
| Property | Value |
|---|---|
| Customs tariff number | 85322200 |
| Country of origin | JP |
Compliance
| Property | Value |
|---|---|
| RoHS conform | Yes |
| SVHC free | Yes |
| Date of RoHS guidelines | 3/31/15 |
