DC/DC converter, RAC04-05SK/277, RECOM
The RAC04-05SK/277 delivers an uncompromising 4 watts of continuous output power (6W peak) in harsh industrial and household environments. This module delivers full load output power from -40°C to 75°C across the entire input range of 80VAC to 305VAC and is certified for operation with power derating up to 90°C air ambient. A peak load capability of up to 150% supports dynamic power demands of applications. This fully encapsulated AC/DC module is a complete solution without the need for external components, supporting Ecodesign Lot 6 standby mode operation for worldwide applications in automation, industry 4.0, IoT, household, and home automation. With international safety and EMC certifications for industrial, domestic, ITE, and household applications, this is one of the most versatile power modules on the market. Due to its reinforced class II installation rating for floating outputs, its significantly wide margin to class B emissions compliance without external components, and a certified 4kV AC (5.25 kV DC) isolation, this is one of the easiest to use modular power solutions in the industry.
