583389-000 | Raychem
Insulated flat plug sleeve, 6.35 x 0.81 mm, 3.0-6.0 mm², AWG 12 to 10, tin, yellow, 583389-000
NCNR (non cancelable / non returnable)
Unit Price (€ / pc.)
1.2852 € *
Available in 12 Days: 22,035 pcs. - if ordered today
Flat plug sleeve Raychem B-106-3633
DuraSeal Heat-Shrinkable Environmentally, sealed, nylon insulated crimp terminals and disconnects, tab size 0.25 x 0.32 inches, Color yellow, partially insulated, 12 – 10 AWG, 3 – 6 mm² Wire, single crimp, straight, tin plating, closed barrel, -55 – 125 °C (-67 – 257 °F).
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Version | flat plug sleeve | |
| Suitable for | 6.35 x 0.81 mm | |
| Material | tin | |
| Isolated | Yes | |
| Insulation colour | yellow | |
| Connection | crimp connection | |
| Cable cross-section | 3.0-6.0 mm² | |
| AWG cross-section | AWG 12 to 10 | |
| Length | 33 mm |
Download
Logistics
| Property | Value |
|---|---|
| Customs tariff number | 85366990 |
| Country of origin | US |
Compliance
| Property | Value |
|---|---|
| Date of RoHS guidelines | 3/31/15 |
| RoHS conform | Yes |
| SVHC free | Yes |
