NB13624001 | Raychem
Heatshrink tubing, 2:1, (9.5/4.8 mm), PE, green, NB13624001
Unit Price (€ / mtr.)
3.6414 € *
Available: 82 mtr.
Available in 5 Days: 2,160 mtr. - if ordered today
Total Price:
3.64 € *
Price list
Quantity
Price per unit*
1 mtr.
3.6414 €
10 mtr.
3.3677 €
25 mtr.
3.1416 €
50 mtr.
2.8441 €
*incl. VAT plus shipping costs
Subject to prior sale
Heat shrink tubing, NB13624001, Raychem
The NB13624001 is a high-quality, heat-shrinkable product for a wide variety of uses. It has become the industry standard for insulation, strain relief, wire bundling, and color-coding in both commercial and military applications. This product's tubing has excellent physical, chemical, and electrical properties that meet industrial and military requirements for a highly reliable, general-purpose tubing.
Features
- 2:1 shrink ratio
- Flexible: conforms to irregular shapes
- Flame-retardant
- RoHS compliant
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Inner diameter before shrinkage | 9.5 mm | |
| max. operating temperature | 135 °C | |
| min. operating temperature | -55 °C | |
| Colour | green | |
| Inner diameter after shrinkage | 4.8 mm | |
| Material | PE | |
| Wall thickness | 0.64 mm | |
| Shrinking rate | 2:1 | |
| Shrinking temperature | 95 °C | |
| Inch Size | 3/8 |
Download
Logistics
| Property | Value |
|---|---|
| Customs tariff number | 39269097 |
| Country of origin | CZ |
Compliance
| Property | Value |
|---|---|
| RoHS conform | Yes |
| SVHC free | Yes |
| Date of RoHS guidelines | 3/31/15 |
