CC0042-000 | Raychem
Heatshrink tubing, 3:1, (2.39/0.79 mm), PE, yellow, CC0042-000
Order No.: 72P2481
EAN: 4099891655495
MPN:
CC0042-000
Unit Price (€ / pc.)
1.1424 € *
Available in 5 Days: 5,000 pcs. - if ordered today
Total Price:
5.71 € *
Price list
Quantity
Price per unit*
5 pcs.
1.1424 €
10 pcs.
1.0591 €
25 pcs.
0.9877 €
50 pcs.
0.8925 €
*incl. VAT plus shipping costs
Subject to prior sale
Heat shrink tubing, CC0042-000, Raychem
The CC0042-000 is a thin wall, heat shrink tube, manufactured with e-beam technology that gives the ability to shrink the supplied tube with no damage. This product is the foremost fluid resistant product used in applications where exposure to lubricant and fuel spray is possible.
Features
- Self-extinguishing, non-flame propagating
- Designed for rugged environment
- Military grade performance
- Resistant to key rail, industrial and military fluids
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Inner diameter after shrinkage | 0.79 mm | |
| Material | PE | |
| Wall thickness | 0.51 mm | |
| min. operating temperature | -75 °C | |
| Shrinking rate | 3:1 | |
| Inch Size | 2.4 | |
| Colour | yellow | |
| Inner diameter before shrinkage | 2.39 mm | |
| Length | 16.7 mm | |
| max. operating temperature | 135 °C |
Download
Logistics
| Property | Value |
|---|---|
| Country of origin | CZ |
| Customs tariff number | 39269097 |
Compliance
| Property | Value |
|---|---|
| SVHC free | Yes |
| Date of RoHS guidelines | 3/31/15 |
| RoHS conform | Yes |
