5038114002 | Raychem
Heatshrink tubing, 2:1, (12/6 mm), PE, yellow/green, 5038114002
Unit Price (€ / mtr.)
5.1289 € *
Standard delivery time from the manufacturer is: 21 Weeks
Heat shrink tubing, D-SCE-1K-25-50-4, Raychem
D-SCE-1K-25-50-4 is the market leading fluid resistant heat shrinking wire marker. It is used in applications where exposure to organic fluids, especially oils, is required for long periods at elevated temperatures.
Features
- 3:1 Shrink ratio
- Diesel Resistant
- Provides the wire with strain relief
- Insulation and protection from mechanical abuse
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Inner diameter before shrinkage | 12 mm | |
| Wall thickness | 0.65 mm | |
| Material | PE | |
| Shrinking rate | 2:1 | |
| Shrinking temperature | 95 °C | |
| max. operating temperature | 135 °C | |
| contains glue inside | No | |
| min. operating temperature | -55 °C | |
| Colour | yellow/green | |
| Inner diameter after shrinkage | 6 mm |
Download
Logistics
| Property | Value |
|---|---|
| Country of origin | IT |
| Customs tariff number | 39173200 |
Compliance
| Property | Value |
|---|---|
| Date of RoHS guidelines | 3/31/15 |
| RoHS conform | Yes |
| SVHC free | Yes |
