CX7799-000 | Raychem
Butt connector kit with heat shrink insulation, 0.25-0.34 mm², AWG 24 to 22, transparent blue, 106 mm, CX7799-000
Order No.: 34P2259
EAN: 4099889604801
MPN:
CX7799-000
D-150-0381
Unit Price (€ / pc.)
56.7035 € *
Standard delivery time from the manufacturer is: 20 Weeks
Splices, CX7799 - 000, Raychem
Splice Product Type: Splice Kit, Sealable: Yes, Splice Type: SolderShield, Splice Wire/Cable Type: Multi - Conductor, Insulated: Yes, Number of Conductors: Two - conductor cable, Plating Material: Nickel, Terminal & Splice Type: Splice, Wire Size: 22 - 24 AWG, Wire Size: 0.34 - 0.25 mm², Splice Wire Insulation Diameter (Max): 6 mm, Wire Size: 304 - 1510 CMA, Splice Overall Length: 106 mm, Insulation Requirement: Fully Insulated, Operating Temperature Range: - 55 - 150 °C
Technical specifications
| Version | butt connector kit | |
| Cable cross-section | 0.25-0.34 mm² | |
| AWG cross-section | AWG 24 to 22 | |
| Isolated | Yes | |
| Colour | transparent blue | |
| Material | PVDF | |
| shrinkable tubing | Yes | |
| Length | 106 mm |
Download
Logistics
| Country of origin | PL |
| Customs tariff number | 85369095 |
Compliance
| Date of RoHS guidelines | 3/31/15 |
| Substance description | Lead |
| SVHC free | No |
| RoHS conform | No |
