1.30.270.401/0101 | RAFI
Pushbutton, unlit, groping, waistband round, white, front ring silver, mounting Ø 22.3 mm, 1.30.270.401/0101
Unit Price (€ / pc.)
12.5545 € *
Available: 3 pcs.
Push button, 1.30.270.401/0101, RAFI
Pushbutton, protruding front ring, round collar, momentary contact function, frontring black, bezel black
Technical Data
- Type of mounting: Threaded ring
- Collar shape: round
- Installation diameter: 22.3 mm
- Installation depth: 9.2 mm
- Installation height: 12.85 mm
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Type of mounting | threaded ring | |
| Protection class | IP65 | |
| Contact function | groping | |
| Product type | pushbutton | |
| Collar shape of the front frame | round | |
| can be illuminated | No | |
| Installation height | 12.85 mm | |
| Front ring colour | silver | |
| Installation diameter | 22.3 mm | |
| Installation depth | 9.2 mm | |
| Actuator colour | white |
Download
Logistics
| Property | Value |
|---|---|
| Country of origin | HU |
| Customs tariff number | 85365080 |
Compliance
| Property | Value |
|---|---|
| Date of RoHS guidelines | 3/31/15 |
| SVHC free | Yes |
| RoHS conform | Yes |
