ML50.102 | PULS

Power supply, 12 to 15 VDC, 4.2 A, 50 W, ML50.102

Order No.: 25K4330
EAN: 4099891283438
MPN:
ML50.102
Series: MiniLine-Serie
ML50.102 PULS DIN Rail Power Supplies
Image may differ
Unit Price (€ / pc.)
117.2031 € *
Standard delivery time from the manufacturer is: On Request
Total Price:
1,406.44 € *
*incl. VAT plus shipping costs
Subject to prior sale
12 pcs.
117.2031 €

Power supplies, type PULS MiniLine.

In robust plastic housing; Operating temperatures: –10 to +70 °C. Certifications: CE, UL, IEC 60950-1.

Single-phase, 4.2 A output current, type ML50.102.

Supports parallel mode; Input voltage: 100 to 240 VAC (-15/+10 %), 100 to 300 VDC (-20/+25 %). Output ripple: 50 mVpp. Connections: spring force. MTBF: 2365 kh. Additional certifications: cUL. Dimensions: W 45, H 75, D 91 mm. Weight: 260 g.

Technical attributes (type, output voltage, output power, backup time 120/230 VAC, efficiency 120/230 VAC): ML50.102, 12 to 15 V, 50 W, 40/180 ms, 87.5/90 %

Technical specifications
Filter Property Value
Height 75 mm
Degree of protection (IP) IP20
Output current 4.2 A
Width 45 mm
efficiency 90 %
Number of outputs 1
Input voltage AC 100-240 VAC, 110-300 VDC
Power 50 W
Output voltage DC 12 to 15 VDC
Depth 91 mm
Logistics
Property Value
Country of origin CN
Customs tariff number 85043180
Compliance
Property Value
RoHS conform Yes
Date of RoHS guidelines 3/31/15
SVHC free No
Substance description Lead
