ML30.101 | PULS

Power supply, 5 to 5.5 VDC, 5 A, 25 W, ML30.101

Order No.: 25K4334

EAN: 4099891283452

MPN:

ML30.101

Series: MiniLine-Serie

Image may differ

Key Specification:

Number of outputs 1

Output current 5 A

Output voltage DC 5 to 5.5 VDC

Download Datasheet Technical specifications

This item is no longer available.

As an alternative, we recommend the following item:

Power supply, 5 to 5.5 VDC, 3 A, 15 W, ML15.051

Order No.: 25K4326

Manufacturer: PULS

per pc. 59.381 € *

Go to product

*incl. VAT plus shipping costs

Description

Power supplies, type PULS MiniLine.

In robust plastic housing; Operating temperatures: –10 to +70 °C. Certifications: CE, UL, IEC 60950-1.

Single-phase, 5.0 A output current, type ML30.101.

Supports parallel and series mode; Input voltage: 100 to 240 VAC (-15/+10 %), 110 to 300 VDC (-20/+25 %). Output ripple: 50 mVpp. Connections: spring force. MTBF: 1963 kh. Additional certifications: cUL. Dimensions: W 45, H 75, D 91 mm. Weight: 240 g.

Technical attributes (type, output voltage, output power, backup time 120/230 VAC, efficiency 120/230 VAC): ML30.101, 5.0 V, 25 W, 52/230 ms, 79/80 %

Technical specifications

Filter	Property	Value
	Number of outputs	1
	Output current	5 A
	Output voltage DC	5 to 5.5 VDC
	Input voltage AC	100-240 VAC, 110-300 VDC
	Power	25 W
	efficiency	80 %
	Degree of protection (IP)	IP20
	Width	45 mm
	Height	75 mm
	Depth	91 mm
