5110/G-F-1.2NE-AU-2.3 C | PTR
Thread test pin with probe, flathead, Ø 2.65 mm, travel 3.5 mm, pitch 4 mm, L 22.5 mm, 5110/G-F-1.2NE-AU-2.3 C
Unit Price (€ / pc.)
11.3526 € *
Standard delivery time from the manufacturer is: 3 Weeks
Total Price:
11.35 € *
Price list
Quantity
Price per unit*
1 pcs.
11.3526 €
10 pcs.
10.0793 €
100 pcs.
8.7346 €
250 pcs.
8.0801 €
1000 pcs.
7.4256 €
*incl. VAT plus shipping costs
Subject to prior sale
Threaded test probes with probe tip type PTR 5110/G.
Grid: 4.0 mm. Maximum travel: 3.5 mm. Working travel: 2.8 mm. Spring force at working travel (±20 %): 1.5 N. Spring prestress: 0.45 N. Current load: max. 10 A. Contact resistance: typically 10 mohm. Barrel: gold-plated brass. Spring: stainless steel, gold-plated.
Type: 5110/G-F-1,5 N-Au-2,3C, F, D 2.3 mm, gold-plated CuBe.
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Head shape | flathead | |
| Rated current | 10 A | |
| Stroke | 3.5 mm | |
| Grid | 4 mm | |
| Length | 22.5 mm | |
| diameter | 2.65 mm | |
| Material | brass |
Download
Logistics
| Property | Value |
|---|---|
| Country of origin | DE |
| Customs tariff number | 85369095 |
Compliance
| Property | Value |
|---|---|
| RoHS conform | Yes |
| SVHC free | Yes |
| Date of RoHS guidelines | 3/31/15 |
