3-1393249-9 | Potter & Brumfield
Circuit breaker, thermal, 1 pole, 1 A, 50 V (DC), 250 V (AC), screw connection, panel mounting, 3-1393249-9
Order No.: 82P3417
MPN:
3-1393249-9
Unit Price (€ / pc.)
22.7052 € *
Available in 5 Days: 699 pcs. - if ordered today
Total Price:
22.71 € *
Price list
Quantity
Price per unit*
1 pcs.
22.7052 €
10 pcs.
21.0749 €
25 pcs.
19.6707 €
50 pcs.
17.8857 €
*incl. VAT plus shipping costs
Subject to prior sale
Circuit breaker, 3-1393249-9, Potter & Brumfield
Thermal Circuit Breaker, Series Trip, White Actuator, 250 VAC, 50 VDC, 1 A, 1 Pole, 10 - 45 seconds Trip Time at 200%, Potter and Brumfield W58.
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Pin number | 1 pole | |
| Version | thermal | |
| Rated voltage (DC) | 50 V | |
| Product type | circuit breaker | |
| Type of mounting | panel mounting | |
| Rated current | 1 A | |
| Rated voltage (AC) | 250 V | |
| Actuator | push actuator | |
| Connection | screw connection |
Download
Logistics
| Property | Value |
|---|---|
| Country of origin | CN |
| Customs tariff number | 85362010 |
Compliance
| Property | Value |
|---|---|
| SVHC free | No |
| Date of RoHS guidelines | 3/31/15 |
| RoHS conform | Yes |
