PC16 SH 10IP061AI 100K | Piher

Carbon potentiometer with rotary switch, 100 kΩ, 0.2 W, linear, solder pin, PC16 SH 10IP061AI 100K

Order No.: 68E378
EAN: 4099879971142
MPN:
PC16 SH 10IP061AI 100K
Series: PC16 SH
PC16 SH 10IP061AI 100K Piher Potentiometers Image 1
PC16 SH 10IP061AI 100K Piher Potentiometers Image 2
Image may differ
Unit Price (€ / pc.)
5.2122 € *
Available: 100 pcs.
Total Price:
5.21 € *
Price list
Quantity
Price per unit*
1 pcs.
5.2122 €
10 pcs.
3.7247 €
100 pcs.
3.1773 €
500 pcs.
2.7727 €
1000 pcs.
2.5109 €
*incl. VAT plus shipping costs
Subject to prior sale

Panel mount potentiometer, PC16 SH 10IP061AI 100K, Piher

ThePC16 SH 10IP061AI 100K is a single-turn panel control potentiometer using a carbon resistive element with plastic housing and incorporated shaft.

Applications

  • Thermostat adjustment
  • HVAC control
  • Consumer electronics
  • Industrial controls
  • Automotive control
  • Home and building automation
Technical specifications
Filter Property Value
ohmic resistance 100 kΩ
max. operating temperature 70 °C
Length 16 mm
min. operating temperature -25 °C
Assembly angled
axle diameter 6 mm
Width 13.6 mm
Track Taper linear
Rotary range, electrical 280 °
Power 0.2 W
Connection solder pin
Mechanic rotary range 300 °
Version carbon potentiometer with rotary switch
Logistics
Property Value
Customs tariff number 85334010
Original Packaging Ammopack with 50 pieces
Country of origin CN
Compliance
Property Value
RoHS conform Yes
SVHC free Yes
Date of RoHS guidelines 3/31/15
