P 6220 | PeakTech
Switching power supply, 1,5 bis 15 VDC, outputs: 1 (2 A), 0 to 2 A, 100-240 VAC, P 6220
NCNR (non cancelable / non returnable)
Mini power supply, P 6220, PeakTech
The PeakTech 6220 is a handy and lightweight DC switching power supply, which impresses with its high performance at the best price/performance ratio. The switching power supply technology used ensures high performance with a small size and low weight. The output voltage is continuously regulated via a potentiometer on the front, whereby the current is limited to a maximum of 2A. With the pole terminals with a 4 mm opening, you can easily connect individual wires but also connect 4 mm banana plugs. The mains cable with a Euro plug is firmly connected to the power supply unit, with the device being switched on and off via the front-side power switch. This handy power supply fits on every workbench and can be used universally in the hobby area, service or training.
Features
- Modern switching power supply technology
- Stabilized output voltage
- Passive cooling and fixed power cord (130cm)
Content
- User manual
| Filter | Property | Value |
|---|---|---|
| Output voltage DC | 1.5 to 15 VDC | |
| Output current | 2 A | |
| Range of Output Currence | 0 to 2 A | |
| Input voltage AC | 100-240 VAC | |
| Number of outputs | 1 | |
| Width | 115 mm | |
| Height | 60 mm | |
| Depth | 140 mm |
| Property | Value |
|---|---|
| Country of origin | CN |
| Customs tariff number | 85044083 |
| Property | Value |
|---|---|
| RoHS conform | Yes |
| Date of RoHS guidelines | 3/31/15 |
| SVHC free | Yes |
