Flow meter, PCE-UFM 4, PCE Instruments

The PCE-UFM 4 flow meter offers the capability to measure flow rates from ±0.1 m/s to ±5 m/s using ultrasonic technology. This HVAC meter is suitable for small pipes with a diameter of DN4 and is compatible with various pipe materials such as steel, copper, aluminum, and plastics. Due to its compact design, it can be quickly and easily mounted on the pipe.

This HVAC meter can be used in various applications, including heating systems, cooling water systems, and industrial processes where flow monitoring and control are necessary.

Features

  • Display of flow, Volume flow
  • Pipe size: DN4
  • Suitable for various pipe materials and media

Scope of delivery

  • 1 x Flow meter for fixed installation PCE-UFM 4
  • 1 x connecting cable 2 m
  • 4 x coupling pad
Technical specifications
Version for pipe size DN4
Accuracy 2 %
measurement range 0.1 to 5 m/s
Product type flow meter
min. operating temperature -10 °C
max. operating temperature 50 °C
Resolution 0.001 m/s
Degree of protection (IP) IP54
Logistics
Customs tariff number 90261021
Country of origin CN
Compliance
SVHC free Yes
Date of RoHS guidelines 3/31/15
RoHS conform Yes
