SF312D | Panasonic

Safety relays, 3 Form A (N/O) + 1 Form B (N/C), 12 V (DC), 288 Ω, 6 A, 30 V (DC), 250 V (AC), SF312D

Order No.: 34G9161
EAN: 4099889421705
MPN:
SF312D
Series: SF3
SF312D Panasonic Monitoring Relays
Image may differ
Unit Price (€ / pc.)
26.0967 € *
Standard delivery time from the manufacturer is: On Request
Total Price:
521.93 € *
*incl. VAT plus shipping costs
Subject to prior sale
20 pcs.
26.0967 €

Safety relay, SF312D, PANASONIC

The SF312D is a slim compact safety relay with improved anti-shock properties meaning that the relay can be safely used in high shock and vibration environments such as in machine tools and other factory equipment. Also has a built-in LED that eliminates the need for design and mounting of separate LED circuit.

Features

  • Fast response time is achieved
  • Circuit is quickly opened to ensure safety
  • High shock resistance

Applications

  • Machine tools
  • Robots
  • Safety PLCs
Technical specifications
Switching Voltage (AC) 250 V
switching current 6 A
Switching Voltage (DC) 30 V
Coil voltage (DC) 12 V
Connection PCB connection
Contact type 3 Form A (N/O) + 1 Form B (N/C)
Contact material AgSnO2
Coil resistance 288 Ω
Logistics
Country of origin CZ
Customs tariff number 85364900
Compliance
Date of RoHS guidelines 3/31/15
SVHC free Yes
RoHS conform Yes
