TX2-5V-1 | Panasonic

Relay, 2 Form C (NO/NC), 5 V (DC), 178 Ω, 1 A, 220 V (DC), monostable, TX2-5V-1

Order No.: 34G9569
EAN: 4099889411140
MPN:
TX2-5V-1
Series: TX2
TX2-5V-1 Panasonic Industrial Relays
Image may differ
Unit Price (€ / pc.)
4.1888 € *
Standard delivery time from the manufacturer is: On Request
Total Price:
167.55 € *
*incl. VAT plus shipping costs
Subject to prior sale
40 pcs.
4.1888 €

Power relay, TX2-5V-1, PANASONIC

Features

  • High breakdown voltage between contact and coil
  • Outstanding surge resistance
  • Outstanding vibration and shock resistance
  • High contact capacity

Applications

  • Communications
  • Measurement
  • Home appliances and audio/visual equipment
  • Automotive equipment
Technical specifications
Filter Property Value
Contact material Ag + Au
Coil resistance 178 Ω
Coil type monostable
Contact type 2 Form C (NO/NC)
Connection PCB connection
switching current 1 A
Switching Voltage (DC) 220 V
Coil voltage (DC) 5 V
Logistics
Property Value
Customs tariff number 85364900
Country of origin JP
Compliance
Property Value
RoHS conform Yes
SVHC free Yes
Date of RoHS guidelines 3/31/15
