DE2A24D | Panasonic
Relay, 2 Form A (N/O), 24 V (DC), 2.88 kΩ, 30 V (DC), 250 V (AC), monostable, DE2A24D
Unit Price (€ / pc.)
10.1150 € *
Standard delivery time from the manufacturer is: 15 Weeks
Total Price:
202.30 € *
Price list
Quantity
Price per unit*
20 pcs.
10.1150 €
40 pcs.
9.7699 €
160 pcs.
9.2225 €
500 pcs.
8.7941 €
*incl. VAT plus shipping costs
Subject to prior sale
Power relays, type Panasonic DE.
With high breaking capacity, compact design; Contact material: AgSnO2. Power consumption: max. 200 mW. Response/decay time: max. 10/5.0 ms. Ambient temperatures: –40 to +70 °C. Certifications: VDE, UL, CSA.
Monostable relays, 2 NO contacts, type DE.
Breaking capacity: 8.0 A/250 VAC, 8.0 A/30 VDC.
Technical attributes (type, rated voltage, coil resistance (±10 %)): DE2A-24V, 24 VDC, 2880 ohm
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Coil voltage (DC) | 24 V | |
| Switching Voltage (DC) | 30 V | |
| Coil resistance | 2.88 kΩ | |
| Contact type | 2 Form A (N/O) | |
| Switching Voltage (AC) | 250 V | |
| Coil type | monostable | |
| Contact material | AgSnO2 |
Download
Logistics
| Property | Value |
|---|---|
| Customs tariff number | 85364900 |
| Original Packaging | Bar with 20 pieces |
| Country of origin | DE |
Compliance
| Property | Value |
|---|---|
| RoHS conform | Yes |
| SVHC free | Yes |
| Date of RoHS guidelines | 3/31/15 |
