EEUFC1J470 | Panasonic
Electrolytic capacitor, 47 µF, 63 V (DC), ±20 %, radial, pitch 3.5 mm, Ø 8 mm, EEUFC1J470
Unit Price (€ / pc.)
0.5236 € *
Available: 2,033 pcs.
Total Price:
5.24 € *
Price list
Quantity
Price per unit*
10 pcs.
0.5236 €
50 pcs.
0.3689 €
250 pcs.
0.3082 €
1000 pcs.
0.2630 €
2500 pcs.
0.2321 €
*incl. VAT plus shipping costs
Subject to prior sale
Aluminium electrolytic capacitor, EEUFC1J470, Panasonic
Radial Lead Type
Features
- Endurance: 105 °C 1000 h to 5000 h
- Low impedance
- RoHS compliant
Applications
- Audio/Visual equipment
- Optical equipment
- Measuring equipment
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Rated voltage (DC) | 63 V | |
| Length | 11.5 mm | |
| Design | radial | |
| max. operating temperature | 105 °C | |
| min. operating temperature | -55 °C | |
| diameter | 8 mm | |
| Ripple current | 405 mA | |
| Version | polar | |
| Capacity | 47 µF | |
| Tolerance | ±20 % | |
| Grid | 3.5 mm | |
| ESR (Equivalent Series Resistance) | 342 mΩ |
Download
Logistics
| Property | Value |
|---|---|
| Country of origin | MY |
| Customs tariff number | 85322200 |
| Original Packaging | Bulk with 200 pieces |
Compliance
| Property | Value |
|---|---|
| RoHS conform | Yes |
| SVHC free | Yes |
| Date of RoHS guidelines | 3/31/15 |
