EEUFC1J101L | Panasonic
Electrolytic capacitor, 100 µF, 63 V (DC), ±20 %, radial, pitch 3.5 mm, Ø 8 mm, EEUFC1J101L
Unit Price (€ / pc.)
0.5950 € *
Available: 486 pcs.
Total Price:
0.60 € *
Price list
Quantity
Price per unit*
1 pcs.
0.5950 €
10 pcs.
0.3689 €
50 pcs.
0.3332 €
250 pcs.
0.3094 €
1000 pcs.
0.2880 €
*incl. VAT plus shipping costs
Subject to prior sale
Aluminium electrolytic capacitor, EEUFC1J101L, Panasonic
Radial Lead Type
Features
- Endurance: 105 °C 1000 h to 5000 h
- Low impedance
- RoHS compliant
Applications
- Audio/Visual equipment
- Optical equipment
- Measuring equipment
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Rated voltage (DC) | 63 V | |
| Length | 15 mm | |
| Design | radial | |
| max. operating temperature | 105 °C | |
| min. operating temperature | -55 °C | |
| diameter | 8 mm | |
| Ripple current | 535 mA | |
| Version | polar | |
| Capacity | 100 µF | |
| Tolerance | ±20 % | |
| Grid | 3.5 mm | |
| ESR (Equivalent Series Resistance) | 230 mΩ |
Download
Logistics
| Property | Value |
|---|---|
| Country of origin | MY |
| Customs tariff number | 85322200 |
| Original Packaging | Bulk with 200 pieces |
Compliance
| Property | Value |
|---|---|
| RoHS conform | Yes |
| SVHC free | Yes |
| Date of RoHS guidelines | 3/31/15 |
