EEUFC1E472 | Panasonic

Electrolytic capacitor, 4700 µF, 25 V (DC), ±20 %, radial, pitch 7.5 mm, Ø 18 mm, EEUFC1E472

Order No.: 38D2011
EAN: 4099879874993
MPN:
EEUFC1E472
Series: FC-A
EEUFC1E472 Panasonic Electrolytic Capacitors Image 1
EEUFC1E472 Panasonic Electrolytic Capacitors Image 2
Image may differ
Unit Price (€ / pc.)
2.975 € *
Standard delivery time from the manufacturer is: On Request
Total Price:
743.75 € *
*incl. VAT plus shipping costs
Subject to prior sale
250 pcs.
2.975 €

Aluminium electrolytic capacitor, EEUFC1E472, Panasonic

Radial Lead Type

Features

  • Endurance: 105 °C 1000 h to 5000 h
  • Low impedance
  • RoHS compliant

Applications

  • Audio/Visual equipment
  • Optical equipment
  • Measuring equipment
Technical specifications
Filter Property Value
Grid 7.5 mm
Ripple current 3680 mA
min. operating temperature -55 °C
max. operating temperature 105 °C
Version polar
diameter 18 mm
Rated voltage (DC) 25 V
Tolerance ±20 %
Capacity 4700 µF
ESR (Equivalent Series Resistance) 15 mΩ
Design radial
Length 35.5 mm
Logistics
Property Value
Customs tariff number 85322200
Country of origin MY
Original Packaging Bulk with 250 pieces
Compliance
Property Value
RoHS conform Yes
SVHC free Yes
Date of RoHS guidelines 3/31/15
