EEEFN1A100R | Panasonic

Electrolytic capacitor, 10 µF, 10 V (DC), SMD, Ø 4 mm, EEEFN1A100R

Order No.: 38D5140
EAN: 4099891913359
MPN:
EEEFN1A100R
Series: FN
EEEFN1A100R Panasonic Electrolytic Capacitors
Image may differ
Unit Price (€ / pc.)
0.1273 € *
Standard delivery time from the manufacturer is: On Request
Total Price:
254.66 € *
*incl. VAT plus shipping costs
Subject to prior sale
2000 pcs.
0.1273 €

Electrolytic capacitor, EEEFN1A100R, Panasonic

Surface mount aluminum electrolytic capacitor is used in electronic applications for it's compact size and high capacitance value.

Features

  • High capacitance
  • AEC-Q200 compliant
  • RoHS compliant
Technical specifications
Rated voltage (DC) 10 V
Capacity 10 µF
diameter 4 mm
Length 5.8 mm
Version polar
Design SMD
ESR (Equivalent Series Resistance) 1.35 Ω
min. operating temperature -55 °C
max. operating temperature 105 °C
Ripple current 90 mA
Logistics
Country of origin MY
Customs tariff number 85322200
Original Packaging Reel with 2,000 pieces
Compliance
Date of RoHS guidelines 3/31/15
SVHC free Yes
RoHS conform Yes
