ASFP60391 | Panasonic
DC axial fan, 12 V, 60 x 60 x 25 mm, 36.6 m³/h, 30.5 dB, ball bearing, Panasonic ASFP60391
Unit Price (€ / pc.)
28.6909 € *
Standard delivery time from the manufacturer is: On Request
DC Axial fan, ASFP60391, PANASONIC
Features
- Reverse polarity power connection
- Ball bearing system
- Rated voltage: 12 V DC
- Material housing: plastic
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Version | DC axial fan | |
| Rated voltage | 12 V | |
| Width | 60 mm | |
| Height | 60 mm | |
| Depth | 25 mm | |
| Volume flow | 36.6 m³/h | |
| Sound pressure level | 30.5 db | |
| speed | 4050 1/min | |
| Type of bearing | ball bearing | |
| Power consumption | 1.92 W |
Download
Logistics
| Property | Value |
|---|---|
| Country of origin | CN |
| Customs tariff number | 84145925 |
Compliance
| Property | Value |
|---|---|
| SVHC free | Yes |
| RoHS conform | Yes |
| Date of RoHS guidelines | 3/31/15 |
