ASEP80416 | Panasonic
AC axial fan, 230 V, 80 x 80 x 38 mm, 45 m³/h, 33 dB, ball bearing, Panasonic ASEP80416
Unit Price (€ / pc.)
34.0459 € *
Standard delivery time from the manufacturer is: On Request
Total Price:
34.05 € *
Price list
Quantity
Price per unit*
1 pcs.
34.0459 €
10 pcs.
31.6540 €
25 pcs.
29.1312 €
50 pcs.
25.6088 €
*incl. VAT plus shipping costs
Subject to prior sale
AC Axial fan, ASEP80416, PANASONIC
Features
- Low rated current
- Impedance protected
- Rated voltage 230 V DC
- Housing made of aluminum alloy die-casting
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Version | AC axial fan | |
| Rated voltage | 230 V | |
| Width | 80 mm | |
| Height | 80 mm | |
| Depth | 38 mm | |
| Volume flow | 45 m³/h | |
| Sound pressure level | 33 db | |
| speed | 2700 1/min | |
| Type of bearing | ball bearing | |
| Power consumption | 10 W |
Download
Logistics
| Property | Value |
|---|---|
| Country of origin | CN |
| Customs tariff number | 84145925 |
Compliance
| Property | Value |
|---|---|
| Date of RoHS guidelines | 3/31/15 |
| SVHC free | Yes |
| RoHS conform | Yes |
