LW A67C-T2U2-Z | Osram Opto Semi
LED, SMD, white, 0.532 cd, 120°, LW A67C-T2U2-Z
Unit Price (€ / pc.)
0.2820 € *
Standard delivery time from the manufacturer is: On Request
Side LED, LW A67C-T2U2-Z, Osram Opto Semi
LW A67C side LED for ambient lighting.
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Radiation angle | 120 ° | |
| Lens | yellow | |
| Forward Current | 20 mA | |
| max. operating temperature | 100 °C | |
| Length | 4 mm | |
| Number of LEDs | 1 | |
| Light intensity typ. | 0.532 cd | |
| Assembly | SMD | |
| Width | 2.85 mm | |
| min. operating temperature | -40 °C | |
| On-State Voltage | 3.2 V | |
| Colour of the LED | white |
Download
Logistics
| Property | Value |
|---|---|
| Country of origin | MY |
| Customs tariff number | 85414100 |
Compliance
| Property | Value |
|---|---|
| Date of RoHS guidelines | 3/31/15 |
| RoHS conform | Yes |
| SVHC free | Yes |
