LSYT676 | Osram Opto Semi
LED, SMD, PLCC-4, red/yellow, 633 nm, 0.157 cd, 120°, LSYT676
Multi top LED, LSYT676, Osram Opto Semi
The LSYT676 is a two chip LEDs for indicators that allow to display red, green and yellow by color mixing.
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Assembly | SMD | |
| Enclosure | PLCC-4 | |
| Number of LEDs | 2 | |
| Colour of the LED | red/yellow | |
| Light intensity typ. | 0.157 cd | |
| Radiation angle | 120 ° | |
| Lens | clear | |
| On-State Voltage | 2 V | |
| Forward Current | 30 mA | |
| Wavelength | 633 nm | |
| Length | 3.2 mm | |
| Width | 2.8 mm | |
| min. operating temperature | -40 °C | |
| max. operating temperature | 100 °C |
Download
Logistics
| Property | Value |
|---|---|
| Customs tariff number | 85414100 |
| Country of origin | MY |
Compliance
| Property | Value |
|---|---|
| SVHC free | Yes |
| Date of RoHS guidelines | 3/31/15 |
| RoHS conform | No |
