NV24C16MUW3VTBG | onsemi

EEPROM memory, NV24C16MUW3VTBG, onsemi

The NV24C16MUW3VTBG is a EEPROM Serial 16-Kb I²C - Automotive Grade device organized internally as 128 pages of 16 bytes each. This device support both the Standard (100 kHz) as well as Fast (400 kHz) I²C protocol. Data is written by providing a starting address, then loading 1 to 16 contiguous bytes into a Page Write Buffer, and then writing all data to non-volatile memory in one internal write cycle. Data is read by providing a starting address and then shifting out data serially while automatically incrementing the internal address count.

Features

• Fast Write Time (4 ms max)
• Hardware Write Protection for Entire Memory
• Schmitt Triggers and Noise Suppression Filters on I²C Bus Inputs
• Low power CMOS Technology

Applications

• Door module
• Seat control unit
• Fan control unit
• Light management unit
• Engine Start/Stop control unit
• Body computer & energy management unit
