2022120 | OBO Bettermann
Cable gland, M25, 29 mm, IP68, light gray, 2022120
Order No.: 46P1211
EAN: 4012195896579
MPN:
2022120
V-TEC VM25 5x4
Unit Price (€ / pc.)
7.735 € *
Standard delivery time from the manufacturer is: 6 Weeks
Cable gland, 2022120, OBO Bettermann
Cable gland with metric connection thread in cap nut design, suitable for junction boxes, housings, distributor cabinets in private and industrial areas. With strain relief and integrated sealing lip, tested according to DIN EN 62444. Protection class IP68. Can be used between -20°C and +65°C.
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Degree of protection (IP) | IP68 | |
| Material | PA | |
| max. operating temperature | 65 °C | |
| spanner size | 29 mm | |
| Thread size | M25 | |
| Product type | cable gland | |
| min. operating temperature | -20 °C | |
| Colour | light gray | |
| Length | 35 mm |
Download
Logistics
| Property | Value |
|---|---|
| Customs tariff number | 39269097 |
Compliance
| Property | Value |
|---|---|
| SVHC free | Yes |
| Date of RoHS guidelines | 3/31/15 |
| RoHS conform | Yes |
