SD-1110W | Nidec Copal

Encoding rotary switch, 16 pole, BCD-Real, straight, 100 mA/5 VDC, SD-1110W

Order No.: 17G3624
EAN: 4099889202731
MPN:
SD-1110W
Series: SD-1000
SD-1110W Nidec Copal Slide Switches and Coding Switches
Image may differ
Unit Price (€ / pc.)
1.8564 € *
Standard delivery time from the manufacturer is: On Request
Total Price:
92.82 € *
Price list
Quantity
Price per unit*
50 pcs.
1.8564 €
100 pcs.
1.7017 €
*incl. VAT plus shipping costs
Subject to prior sale

Rotary code switch, SD-1110W, Nidec Copal

Features

  • Leadfree soldering
  • Fine click with metallic spring
  • Low profile of 3.9 mm makes perfect for high density board mounting applications
  • Gold plated contact provides excellent reliability
  • Terminal pin arrangement 33
Technical specifications
contact surface gold-plated
Coding BCD-Real
Breaking capacity 100 mA/5 VDC
Grid 2.54 mm
Pin number 16 pole
Version encoding rotary switch
Design straight
Actuation on top
Connection PCB pin
Logistics
Country of origin CN
Customs tariff number 85365080
Original Packaging Bulk with 50 pieces
Compliance
Date of RoHS guidelines 3/31/15
SVHC free Yes
RoHS conform Yes
