LNC2W272MSEG | NICHICON
Electrolytic capacitor, 2700 µF, 450 V (DC), ±20 %, can, pitch 22 mm, Ø 63 mm, LNC2W272MSEG
Unit Price (€ / pc.)
40.8884 € *
Standard delivery time from the manufacturer is: 30 Weeks
Electrolytic capacitor, LNC2W272MSEG, NICHICON
Aluminum electrolytic capacitor - Screw terminal capacitor
Features
- High rated capacitance
- RoHS-compatible
- Long useful life
Applications
- Servo drives
- General Inverter
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Grid | 22 mm | |
| diameter | 63 mm | |
| Connection | screw connection | |
| Rated voltage (DC) | 450 V | |
| max. operating temperature | 85 °C | |
| Tolerance | ±20 % | |
| Length | 90 mm | |
| Capacity | 2700 µF | |
| min. operating temperature | -40 °C | |
| Ripple current | 13 A | |
| Design | can | |
| Version | polar |
Download
Logistics
| Property | Value |
|---|---|
| Country of origin | JP |
| Customs tariff number | 85322200 |
Compliance
| Property | Value |
|---|---|
| Date of RoHS guidelines | 3/31/15 |
| RoHS conform | Yes |
| SVHC free | Yes |
