LGN2X560MELB25 | NICHICON
Electrolytic capacitor, 56 µF, 600 V (DC), ±20 %, radial, pitch 9 mm, Ø 30 mm, LGN2X560MELB25
Unit Price (€ / pc.)
4.1174 € *
Standard delivery time from the manufacturer is: 22 Weeks
Electrolytic capacitor, LGN2X560MELB25, NICHICON
Aluminum electrolytic capacitor - Snap-in capacitor
Features
- Withstanding 3000 hours application of rated ripple current at 105°C.
- High rated capacitance
- RoHS-compatible
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Connection | snap-in | |
| Tolerance | ±20 % | |
| Capacity | 56 µF | |
| diameter | 30 mm | |
| Rated voltage (DC) | 600 V | |
| Grid | 9 mm | |
| max. operating temperature | 105 °C | |
| min. operating temperature | -25 °C | |
| Version | polar | |
| Design | radial | |
| Ripple current | 500 mA | |
| Length | 25 mm |
Download
Logistics
| Property | Value |
|---|---|
| Country of origin | JP |
| Customs tariff number | 85322200 |
Compliance
| Property | Value |
|---|---|
| SVHC free | Yes |
| Date of RoHS guidelines | 3/31/15 |
| RoHS conform | Yes |
