BCP69,115 | NEXPERIA
Bipolar junction transistor, PNP, -2 A, -20 V, SMD, SOT-223, BCP69,115
Discontinued
Unit Price (€ / pc.)
0.2213 € *
Available: 405 pcs.
Total Price:
0.22 € *
Price list
Quantity
Price per unit*
1 pcs.
0.2213 €
100 pcs.
0.1845 €
*incl. VAT plus shipping costs
Subject to prior sale
PNP power transistor, BCP69,115, NEXPERIA
PNP medium power transistor series in surface-mounted device (SMD) plastic packages.
Features
- High current
- High power dissipation capability
- AEC-Q101 qualified
Applications
- Power management
- Battery-driven devices
- Amplifiers
- Low-side switches
- Linear voltage regulators
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Enclosure | SOT-223 | |
| Max DC amplification | 375 mA | |
| Transit frequency fTmin | 140 MHz | |
| Saturation voltage | -500 mV | |
| Min DC gain | 50 mA | |
| Power dissipation | 0.65 W | |
| Assembly | SMD | |
| max.voltage between collector and emitter Vceo | -20 V | |
| max.voltage between collector and base Vcbo | -32 V | |
| max. operating temperature | 150 °C | |
| min. operating temperature | -65 °C | |
| Version | PNP | |
| Collector current | -2 A |
Download
Logistics
| Property | Value |
|---|---|
| Customs tariff number | 85412900 |
| Country of origin | CN |
Compliance
| Property | Value |
|---|---|
| RoHS conform | Yes |
| SVHC free | Yes |
| Date of RoHS guidelines | 3/31/15 |
