NAC3MPXXA | Neutrik
Panel plug, 3 pole, chassis mounting, plug-in connection, 2.5 mm², blue, NAC3MPXXA
Unit Price (€ / pc.)
4.9504 € *
Available: 349 pcs.
Total Price:
4.95 € *
Price list
Quantity
Price per unit*
1 pcs.
4.9504 €
10 pcs.
4.5815 €
25 pcs.
4.2721 €
50 pcs.
3.8675 €
*incl. VAT plus shipping costs
Subject to prior sale
Panel plug, NAC3MPXXA, Neutrik
The NAC3MPXXA is a locking mains connector. It replaces Cold appliance plugs wherever a very reliable solution in combination with a locking device is needed in order to guarantee a safe power connection.
Features
- Lockable single phase connector
- Extremely robust and reliable
- 3 contacts for line, neutral and premating safety ground
- Fast and easy twist lock latching system
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Line filter present | No | |
| Switch illuminated | No | |
| Rated voltage UL/CSA | 250 V | |
| Colour | blue | |
| Connection | plug-in connection | |
| Cable cross-section | 2.5 mm² | |
| Design | straight | |
| Rated current UL/CSA | 20 A | |
| Assembly | chassis mounting | |
| Fuse holder present | No | |
| Rated voltage IEC | 250 V | |
| Product type | panel plug | |
| Pin number | 3 pole | |
| Rated current IEC | 20 A | |
| Power switch available | No |
Download
Logistics
| Property | Value |
|---|---|
| Customs tariff number | 85366990 |
| Country of origin | CH |
Compliance
| Property | Value |
|---|---|
| RoHS conform | Yes |
| SVHC free | Yes |
| Date of RoHS guidelines | 3/31/15 |
