00 6122 08 | Neosid
Suppressor choke, radial, 47 µH, 480 mA, 00 6122 08
Unit Price (€ / pc.)
4.5577 € *
Available: 647 pcs.
Total Price:
4.56 € *
Price list
Quantity
Price per unit*
1 pcs.
4.5577 €
10 pcs.
2.8560 €
50 pcs.
2.4990 €
250 pcs.
2.1777 €
*incl. VAT plus shipping costs
Subject to prior sale
Suppressor inductor, 00 6122 08, NEOSID
The 00 6122 08 is a fixed value choke inductor with or without a ferromagnetic core, used to block alternating current (AC) in a circuit by limiting the rate of change over a specified frequency range, while allowing passage of lower frequency AC or direct current (DC).
Features
- Solderability as per DIN IEC 68-2-20 Ta: 235°C, 5 sec.
Applications
- Decoupling of high and low frequency circuits
- Telecommunications
- Video equipment
- Electronic data processing systems
Technical specifications
| Filter | Property | Value |
|---|---|---|
| DC current | 480 mA | |
| DC resistance | 1.2 Ω | |
| Tolerance | ±5 % | |
| Length | 10.5 mm | |
| Inductance | 47 µH | |
| Quality Q | Q 60 | |
| Width | 7.5 mm | |
| Height | 4.6 mm | |
| Version | suppressor choke | |
| Design | radial | |
| Measuring frequency | 1 MHz |
Download
Logistics
| Property | Value |
|---|---|
| Customs tariff number | 85045000 |
| Country of origin | DE |
Compliance
| Property | Value |
|---|---|
| SVHC free | Yes |
| RoHS conform | Yes |
| Date of RoHS guidelines | 3/31/15 |
