Electrolytic capacitor, 6800 µF, 40 V (DC), ±20 %, radial, pitch 10 mm, Ø 25 mm, MLGO40-6800
No longer in assortment
Unit Price (€ / pc.)
7.6755 € *
Available: 37 pcs.
Electrolytic capacitor for high-end applications, type Mundorf MLytic AG.
Especially for use in small amps and preamps, high thermal conductivity, ultra-thin layers; Dielectric: aluminum oxide. Capacitance tolerance: ±20%. Operating temperatures at 16 to 63 V: –40 to +125 °C, at 80 to 160 V: –25 to 105 °C. Useful life at +125/+105 °C: 1000/2000 h.
Rated voltage 40 VDC.
Technical attributes (type, capacitance, dimensions): MLGO40-6800, 6800 µF, 25 x 35 mm
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Capacity | 6800 µF | |
| diameter | 25 mm | |
| max. operating temperature | 125 °C | |
| Length | 35 mm | |
| min. operating temperature | -40 °C | |
| Grid | 10 mm | |
| Ripple current | 2.7 A | |
| Design | radial | |
| Connection | PCB connection | |
| ESR (Equivalent Series Resistance) | 35 mΩ | |
| Version | polar | |
| Rated voltage (DC) | 40 V | |
| Tolerance | ±20 % |
Download
Logistics
| Property | Value |
|---|---|
| Customs tariff number | 85322200 |
| MSL | MSL 1 |
| Country of origin | DE |
Compliance
| Property | Value |
|---|---|
| RoHS conform | Yes |
| SVHC free | Yes |
| Date of RoHS guidelines | 3/31/15 |
