12 0220 000 05 | MPE-GARRY
Carrier IC socket, 20 pole, pitch 2.54 mm, copper alloy, tin plated for SIL, 12 0220 000 05
Order No.: 15B663
MPN:
12 0220 000 05
220-1-020-D-B1STF-XS0
Unit Price (€ / pc.)
4.1174 € *
Standard delivery time from the manufacturer is: On Request
Precision base strip, 12 0220 000 05, MPE-GARRY
Precision display socket strip with a height of 7.00 mm.
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Rated voltage | 150 V | |
| Suitable for | SIL | |
| Contact material | copper alloy, tin plated | |
| Width | 4.2 mm | |
| Height | 2.54 mm | |
| Material | thermoplastic | |
| max. operating temperature | 125 °C | |
| min. operating temperature | -55 °C | |
| Product type | carrier IC socket | |
| Pin number | 20 pole | |
| Length | 50.8 mm | |
| Grid | 2.54 mm | |
| Rated current | 3 A |
Download
Logistics
| Property | Value |
|---|---|
| Customs tariff number | 85366930 |
| Country of origin | CH |
Compliance
| Property | Value |
|---|---|
| RoHS conform | Yes |
| SVHC free | Yes |
| Date of RoHS guidelines | 3/31/15 |
