001-1-006-3-B1STF-XT0 | MPE-GARRY
IC socket, 6 pole, pitch 2.54 mm (7.62 mm), copper alloy, tin plated for DIL-IC, 001-1-006-3-B1STF-XT0
Unit Price (€ / pc.)
0.5950 € *
Available: 1,193 pcs.
Total Price:
0.60 € *
Price list
Quantity
Price per unit*
1 pcs.
0.5950 €
10 pcs.
0.4165 €
100 pcs.
0.3570 €
500 pcs.
0.3082 €
1000 pcs.
0.2808 €
*incl. VAT plus shipping costs
Subject to prior sale
Flat IC precision sockets, type MPE-GARRY Serie 001.
Insulating body: thermoplastic to UL 94 V-0. Contact material: brass/beryllium copper. Rated current: 1.0 A. Rated voltage: 100 VRMS/150 VDC. Operating temperatures: –55 to +125 °C.
With selective gold-plated female contacts and tinned solder pins, type MP STG B.
Technical attributes (number of poles, dimensions): 001-1-006-3-B1STF-XT0, 6-pole, A 7.54, B 10.08, C 7.62 mm
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Rated current | 3 A | |
| Contact material | copper alloy, tin plated | |
| max. operating temperature | 125 °C | |
| Version | IC socket | |
| Grid | 2.54 mm | |
| Width | 10.08 mm | |
| Material | thermoplastic | |
| Pin number | 6 pole | |
| Height | 3.6 mm | |
| Rated voltage | 150 V | |
| min. operating temperature | -55 °C | |
| Suitable for | DIL-IC | |
| Length | 7.54 mm |
Download
Logistics
| Property | Value |
|---|---|
| Country of origin | DE |
| Customs tariff number | 85366990 |
| Original Packaging | Bar with 69 pieces |
Compliance
| Property | Value |
|---|---|
| SVHC free | Yes |
| RoHS conform | Yes |
| Date of RoHS guidelines | 3/31/15 |
