UART 1-WIRE CLICK
UART 1-Wire click is used to convert standard UART or RS232 signals into 1-Wire signals. Apart from other features such as the slew rate control for larger 1-Wire busses, selectable data rate, an accurate self-calibrating time base, ESD protection and more, the main feature of the UART 1-Wire click, is that it manages all the sensitive signal timings involved in 1-Wire communication, allowing rapid development of UART to 1-Wire applications. It can automatically convert a single character from the UART bus into eight 1-Wire time slots, thereby increasing the data throughput significantly, while reducing the microcontroller workload. UART 1-Wire click is supported by a mikroSDK compliant library, which includes functions that simplify software development. This Click board comes as a fully tested product, ready to be used on a system equipped with the mikroBUS socket.
