MCP1703T-3302E/CB | Microchip
Voltage regulator, 3.3 VDC, 250 mA, positive, TO-263, MCP1703T-3302E/CB
Unit Price (€ / pc.)
0.8925 € *
Standard delivery time from the manufacturer is: 2 Weeks
Total Price:
22.31 € *
Price list
Quantity
Price per unit*
25 pcs.
0.8925 €
100 pcs.
0.8330 €
500 pcs.
0.7140 €
*incl. VAT plus shipping costs
Subject to prior sale
LDO regulator, MCP1703T-3302E/CB, ATMEL
The MCP1703T-3302E/CB is a Low dropout voltage regulator that can deliver up to 250 mA of current while consuming only 2.0 µA of quiescent current. This product is capable of delivering 250 mA with only 625 mV of input to output voltage differential.
Features
- Input operating voltage
- Low dropout voltage
- Short-circuit protection
- Overtemperature protection
Applications
- Battery-powered devices
- Smoke detectors
- CO2 detectors
- Pagers and cellular phones
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Assembly | SMD | |
| Enclosure | TO-263 | |
| Version | fixed | |
| Number of Regulators | 1 | |
| Input voltage AC | 2.7-16 V | |
| Output voltage DC | 3.3 VDC | |
| Output current | 250 mA | |
| Polarity | positive | |
| min. operating temperature | -40 °C | |
| max. operating temperature | 125 °C |
Download
Logistics
| Property | Value |
|---|---|
| MSL | MSL 1 |
| Customs tariff number | 85423390 |
| Country of origin | HK |
| Original Packaging | Reel with 3,000 pieces |
Compliance
| Property | Value |
|---|---|
| RoHS conform | Yes |
| SVHC free | Yes |
| Date of RoHS guidelines | 6/8/11 |
