ASP0250904 | METZ CONNECT
PCB terminal, 9 pole, pitch 5 mm, AWG 28-16, 8 A, spring-clamp connection, gray, ASP0250904
Unit Price (€ / pc.)
4.5696 € *
Available: 463 pcs.
Leadtime: 12 Weeks **
Total Price:
4.57 € *
Price list
Quantity
Price per unit*
1 pcs.
4.5696 €
10 pcs.
4.0103 €
100 pcs.
3.5224 €
250 pcs.
3.3915 €
1000 pcs.
3.1654 €
*incl. VAT plus shipping costs
**Subject to prior sale
PCB terminal, ASP0250904, METZ
It is suitable for solid wires and multi-stranded wires with a nominal cross section of 0.08 - 2.5 mm² and permits direct clamping without preconditioning of the conductor, direct clamping with splice protection and indirect clamping via an end sleeve or pin cable lug.
Features
- Spring terminal block, pluggable
- Direction of connection 90°
- Fittable without loss of poles
- Eccentric lever, wire entry perpendicular to plug direction
Technical specifications
| Connection | spring-clamp connection | |
| AWG cross-section | AWG 28-16 | |
| Colour | gray | |
| Cable cross-section | 0.08-1.0 mm² | |
| Rated voltage | 250 V | |
| Rated current | 8 A | |
| Pin number | 9 pole | |
| Grid | 5 mm |
Download
Logistics
| Country of origin | HU |
| Customs tariff number | 85366990 |
Compliance
| RoHS conform | Yes |
| Date of RoHS guidelines | 3/31/15 |
| SVHC free | Yes |
