100-26TR | METCAL
ETFE-wire wrap wire, 0.13 mm², AWG 26, red, outer Ø 0.71 mm, 100-26TR
Order No.: 91F5014
EAN: 4099891168704
MPN:
100-26TR
This item is no longer available.
As an alternative, we recommend the following item:
ETFE-wire wrap wire, 7Y ETFE, 0.13 mm², AWG 26, red, outer Ø 0.91 mm, 370102608
Order No.: 91F8559
Manufacturer: Kabeltronik
per mtr. 0.6426 € *
Insulated wire-wrap hookup wires, type OK 100.
Compliant with VDE 0881
With 0.4 mm wire thickness, AWG 26, type 100-26.
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Core insulation material | ETFE | |
| AWG cross-section | AWG 26 | |
| Cable material | copper, tin-plated | |
| Colour | red | |
| Cable cross-section | 0.13 mm² | |
| Temperature range (active) | -90 °C to 150 °C | |
| Rated voltage | 375 V | |
| Conductor category | CL.1 = stranded | |
| Test voltage | 1.5 kV | |
| Outer diameter | 0.71 mm | |
| Product type | wire wrap wire |
Download
Logistics
| Property | Value |
|---|---|
| Country of origin | DE |
| Customs tariff number | 85444290 |
Compliance
| Property | Value |
|---|---|
| Date of RoHS guidelines | 3/31/15 |
| SVHC free | Yes |
| RoHS conform | Yes |
