1840.6132 | Mentor
Pushbutton, 2 pole, black, unlit , 0.5 A/60 V, IP50, 1840.6132
Unit Price (€ / pc.)
6.1642 € *
Available: 15 pcs.
Total Price:
6.16 € *
Price list
Quantity
Price per unit*
1 pcs.
6.1642 €
10 pcs.
5.4264 €
100 pcs.
4.7600 €
250 pcs.
4.5815 €
1000 pcs.
4.2721 €
*incl. VAT plus shipping costs
Subject to prior sale
Pushbutton switches, type Mentor 1840.
Switching action: ON-M, momentary, for PCB connection. Housing material: PPA, black. Terminals: tinned. Actuating force: max. 4.0 N, Breaking capacity: 0.5 A/60 V AC/DC. Test voltage: 500 V/50 Hz. Contact resistance: max. 30 mohm. Operating temperatures: –40 to +85 °C. The actuator element can be equipped with separately available snap-on plastic buttons.
Technical attributes (type, number of poles): 1840.6132, double-pole
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Breaking capacity | 0.5 A/60 V | |
| Vandal-proof | No | |
| Actuator colour | black | |
| Connection | solder connection | |
| Printed | No | |
| Latching switching function | groping | |
| Design | round | |
| Protection class | IP50 | |
| Pin number | 2 pole | |
| illuminated | No |
Download
Logistics
| Property | Value |
|---|---|
| Customs tariff number | 85365011 |
| Country of origin | TN |
Compliance
| Property | Value |
|---|---|
| RoHS conform | Yes |
| SVHC free | Yes |
| Date of RoHS guidelines | 3/31/15 |
